SLS3 Stack Labeler

The Eastman SLS3 stack labeler fully automates the labeling process, reducing time, labor, and costly operator errors.

Product Summary

SLS3 Stack Labeling System

The Eastman SLS3 stack labeler fully automates the labeling process, reduces time, labor and eliminates costly errors that can occur with manual labeling. The SLS3 operates on all standard spreading tables and can interface with any CAD system.

The SLS3 replaces large paper patterns or markers used for identification purposes with small, adhesive labels. Accurately print and affix pattern labels to the top layer of fabric stacks up to 4 inches (10.16cm) high. The stacks are then ready to move to a high-ply cutting system where they are cut and bundled.

Automated > System Options

Features

  • Prints and applies labels in one step
  • Thermal print head
  • Adjustable speed control
  • Standard label sizes: 1 in. x 2 in. or 1.25 in. x 0.5 in.
  • Supports numbers 0-9; characters A-Z; +/-/./$/% and SPACE
  • One of seven available barcode types may be selected (standard is CODE39)
  • Accommodates 9 information fields in various font sizes
  • Operates on all standard spreading tables

Download Product PDF

  • Hidden
  • Please complete the below form to download digital assets.

  • Check files to be downloaded:
  • Enter your email address:
  • This field is for validation purposes and should be left unchanged.

Additional Information

Width

Up to 126 inches (3.20m)

Drive System

Brushless Servo Motors

Maximum label stack height

4 inches (10.16 cm)

Power (System Drive)

220V, 1 ph, 20 amps

Disclaimer: Achievable speeds and accelerations are tool, material and thickness dependent. All indicated speeds, dimensions, weights and performance data are approximate and subject to change without notice.
