Ultrasonic Tool Head

The Ultrasonic Tool Head option has been designed for cutting adhesive-backed, composite, or gasket type materials with 20,000 oscillations per second. The ultrasonic technology reduces blade gumming and friction between the material and blade.

Product Summary

Ultrasonic Tool

Eastman precision tools offer the utmost flexibility for hundreds of cutting applications and proven solutions for even the most difficult-to-cut materials. Eastman’s tool heads have been engineered to offer maximum versatility and adaptability while adhering to stringent industry requirements for accuracy, speed and repeated quality.

The Ultrasonic tool head option has been designed for cutting adhesive backed, composite or gasket type materials with 20,000 oscillations per second. The ultrasonic technology reduces blade gumming and friction between the material and blade.

Automated > System Options

Features

  • Individually aligned and calibrated spindles allows choice of two tools, in addition to ultrasonic tool
    • Compatible with complete library of blades, punches, notches and more
  • Stiffer, thicker tool spindles offer less deflection when cutting rigid or dense material
  • Pneumatic pen lift/holder assembly included
  • A library feature within the operating control software allows the operator to save commonly used tool pressures and blade assignments based on job and material files
  • Computer-assisted calibration minimizes downtime after tool changing
  • Eastman tool depth limiters and exclusive tool depth gauges are available to limit the exposure of the blade and minimize blade penetration into the cutting surface.
  • Ultrasonic spindle available with 30, 45 and 55 degree drag blades
  • Frequency: 20,000 Hz (20,000 oscillations per second)

Available for static table and conveyor systems and compatible with JetPRO, LabelPRO and Router Options
